Description
This board sets the Standard for commercial applications. Gyprock Standard 13mm works as a general internal wall and ceiling lining in a huge range of commercial applications.
Product Overview
Gyprock Standard 13mm is manufactured in Australia to meet and exceed the requirements of Australian Standard AS/NZS 2588.
The go-to for commercial construction, Gyprock Standard 13mm can also be used residential to deliver a more robust, acoustically sound lining.
Typical Applications
Gyprock Standard 13mm is typically used as a wall and ceiling lining option in commercial applications including non-fire or acoustic rated walls and partitions.
Product Options
Gyprock Standard 13mm is available in the following sizes:
| Thickness |
13mm |
| Widths |
900mm
1200mm
1350mm
1400mm |
| Lengths |
2400mm
2700mm
3000mm
3600mm
4200mm
4800mm
6000mm |
| Edge Profiles |
Recessed Edge for regular jointing
Recessed Edge/Square Edge for low profile architectural mouldings
Square Edge for applications not requiring jointing |
Manufacturing Tolerances
| Nominal Thickness |
13mm ± 0.5mm |
| Nominal Widths |
900mm, 1200mm, 1350mm, and 1400mm ± 3mm |
| Nominal Lengths |
From 2400 to 6000mm ± 5mm, typically in 300mm increments |
| Squareness |
Cut ends ± 3mm in the width of the board. |
Physical Properties
| Nominal Board Weight*
|
8.5kg/m2
|
| Thermal Resistance |
0.05 - 0.07 m2K/W |
| Fire Hazard Properties∆ |
Group No = 1
SMOGRARC <100 m2/s2
|
| Combustibility◊ |
Plasterboard may be used wherever a non-combustible material is required. |
Total Recycled Content
|
3.7% |
* Subject to reasonable manufacturing variance
∆ In accordance with AS ISO 9705 and AS 5637.1
◊ In accordance with NCC2022 Vol 1 Clause C2D10(6)(a) and NCC2019 Amdt1 Vol Clause C1.9(e)(i).
